The Elevator Geared Traction Machine is designed for reliable passenger elevator operation using a geared drive system. It combines an electric motor, reduction gearbox, traction sheave and braking system to provide controlled movement of the elevator car and counterweight.

Geared traction machines are widely used in Machine Room (MR) elevator installations and are suitable for residential, commercial and institutional passenger lift projects. The correct machine should be selected according to elevator capacity, speed, travel height, roping arrangement and project requirements.

Reliable Geared Elevator Technology

Unlike a gearless traction machine, a geared traction machine transfers motor power to the traction sheave through a reduction gearbox. This arrangement provides the torque required for elevator movement while allowing controlled acceleration, running and stopping.

Proper machine selection, alignment and commissioning are important for smooth operation, passenger comfort and long service life.

Key Features

• Reliable geared traction technology
• Suitable for Machine Room (MR) elevators
• High starting torque for passenger elevator applications
• Smooth and controlled elevator movement
• Heavy-duty mechanical construction
• Integrated electromagnetic braking system
• Compatible with suitable VVVF elevator drives
• Suitable for different passenger capacities
• Designed for new installations and modernization
• Serviceable mechanical construction
• Suitable for compatible elevator controllers
• Professional installation and commissioning supported

Applications

The Elevator Geared Traction Machine can be used for various elevator projects, including:

• Residential apartments
• Commercial buildings
• Office buildings
• Hotels
• Hospitals
• Institutional buildings
• Machine Room passenger elevators
• New elevator installations
• Elevator modernization projects

Final selection should always be based on the actual elevator design and technical specifications.

Machine Room Elevator Application

Geared traction machines are commonly installed in a dedicated elevator machine room. The machine supporting structure, machine bed, traction arrangement and available installation space should be designed according to the selected machine and elevator configuration.

Adequate access should also be provided for inspection, adjustment and future maintenance.

Capacity and Speed Selection

Selection of the correct Elevator Geared Traction Machine depends on several technical factors, including:

• Rated elevator load
• Passenger capacity
• Rated speed
• Travel height
• Number of floors and stops
• Suspension or roping ratio
• Traction sheave specification
• Rope diameter and quantity
• Counterweight arrangement
• Motor power requirement
• Shaft and machine room configuration

Technical requirements should be verified before final machine selection.

VVVF Drive & Controller Compatibility

The geared traction machine can be operated with a compatible VVVF drive and elevator controller according to the selected motor and control configuration.

Motor power, voltage, rated current, brake voltage, feedback requirements and drive specifications should be checked before installation. Correct parameter setting is important for smooth acceleration, deceleration, leveling and stopping.

Roping and Traction System

The traction sheave works with the elevator suspension ropes to move the elevator car and counterweight. Rope diameter, number of ropes, sheave dimensions, groove condition and suspension arrangement must be suitable for the elevator design.

Correct rope tension and alignment are important for reliable traction and service life.

Brake System

The braking system is an important component of the Elevator Geared Traction Machine. Brake operation, clearance, electrical supply and mechanical condition should be inspected during installation and routine maintenance.

Brake adjustment and servicing should only be performed by qualified elevator technicians.

Installation and Commissioning

Installation should be carried out by qualified elevator professionals. Machine mounting, alignment, electrical connections, gearbox condition, brake operation, traction sheave, ropes and controller integration should be checked carefully.

The complete elevator system should be tested and commissioned before passenger operation.

Maintenance

Regular preventive maintenance helps maintain reliable geared traction machine operation. Gearbox lubrication, oil condition, bearings, brake system, traction sheave, ropes, motor connections, mounting bolts and machine alignment should be inspected periodically.

Maintenance requirements may vary according to the selected machine model and operating conditions.

Suitable for New Installation & Modernization

The Elevator Geared Traction Machine can be selected for new Machine Room elevator projects and suitable modernization applications. For modernization projects, the existing shaft, machine room, supporting structure, ropes, controller, drive and other related components should be inspected before machine selection.

Why Choose ORSHA Elevator & Technology?

ORSHA Elevator & Technology supplies elevator components and solutions for new installations, modernization and maintenance projects. Geared traction machines can be selected according to elevator capacity, speed, roping arrangement and compatible control system requirements.

For correct product selection, please provide passenger capacity, rated load, elevator speed, travel height, roping details, shaft dimensions, machine room details and controller or drive specifications before ordering.

For enhanced elevator door safety, you can also explore our Elevator Gearless Traction Machine

Note: Product model, appearance, dimensions, motor power, gearbox ratio, load capacity, speed, traction sheave, brake specifications and other technical details may vary according to the selected model and project requirements. Final specifications and compatibility should be confirmed before purchase and installation.
